Product Specs
- AHRI unit role: Indoor
- AHRI model/pattern: PF5TNBD60L*
- AHRI records represented: 29
- AHRI equipment type: Central HP
- AHRI tonnage: 3.9583333333333335
- AHRI refrigerant: R-454B
- Verified catalog model: PF5TNBD60L00
- Verified product family: PF5T
- Verified catalog brand: Carrier, Bryant, Payne
- Catalog Model: PF5TNBD60L00
- Manufacturer Number: PF5TNBD60L00
- Catalog SKU: 1604089263796024
- Catalog Brand: Carrier, Bryant, Payne
- Product Family: PF5T
- Tonnage: 5
- Refrigerant: R-454B
- Air Flow Direction: Multi-Position
- Approvals: UL Listed
- Blower Motor HP: 3/4
- Blower Motor RPM: 1,050
- Blower Motor Speeds: Variable
- Blower Motor Type: ECM (Electronically Commutated Motor)
- Blower Wheel Diameter: 13 3/4
- Blower Wheel Width: 12 3/4
- Brand: Carrier, Bryant, Payne
- CFM: 1,050-1,750
- Cabinet Width: 24.7
- Color: Gray
- Cooling Capacity: 60,000
- Cooling Rated Capacity Btu/h: 60000
- Country Of Origin: MEX
- Cycle/Hertz: 60 Hz
- Drain Connection Size: 3/4"
- Energy Star Rated: NO
- Evaporator Coil Fins Per Inch (FPI): 14.5
- Filter Size: 24" x 20
- Height: 59.2
- Includes Filter Rack: YES
- Length: 22.1
- Liquid Line Fitting Type: Sweat or Braze
- Liquid Line Size (OD): 3/8"
- Maximum Overcurrent Protection (MOCP): 15
- Metering Device: TXV/TEV - Thermostatic Expansion Valve
- OPT Code: 1PPF5TNBD60L00
- Phase: Single
- Prop 65: YES
- Stage: 2
- Suction Line Fitting Type: Sweat or Braze
- Suction Line Size (OD): 7/8
- Tier: Standard
- UPC: See Optical
- Voltage: 208-230 VAC
- Weight: 210
- Width: 24.7
