Product Specs
- AHRI unit role: Outdoor
- AHRI model/pattern: 248TAN036**AA*
- AHRI records represented: 271
- AHRI equipment type: HP - Split System
- AHRI refrigerant: R-454B
- Verified catalog model: 248TAN03600A
- Verified product family: 248TAN
- Verified catalog brand: Bryant
- Catalog Model: 248TAN03600A
- Manufacturer Number: 248TAN03600A
- Catalog SKU: 1604089257792108
- Catalog Brand: Bryant
- Product Family: 248TAN
- Tonnage: 3
- SEER2: 17
- Refrigerant: R-454B
- Approvals: UL Listed
- Brand: Bryant
- CFM: 965
- Color: Brown
- Compressor Type: Scroll
- Condenser Coil Fins Per Inch (FPI): 20
- Condenser Fan Blade Diameter: 26
- Condenser Fan CFM: 3788
- Condenser Fan Discharge: Vertical
- Condenser Fan Motor Qty: 1
- Condenser Motor HP: 1/3
- Condenser Motor RPM: 700
- Condenser Motor Speeds: 1
- Condenser Motor Type: ECM (Electronically Commutated Motor)
- Cooling Capacity: 33,200-37,600
- Cooling Rated Capacity Btu/h: 36000
- Country Of Origin: USA
- Cycle/Hertz: 60 Hz
- EER2: 14
- Energy Star Rated: YES
- Full Load Amps: 2.6
- Height: 38.875
- Inverter: NO
- Length: 35
- Liquid Line Fitting Type: Sweat or Braze
- Liquid Line Size (OD): 3/8"
- Locked Rotor Amps (LRA): 90
- Maximum Overcurrent Protection (MOCP): 40
- Metering Device: TXV/TEV - Thermostatic Expansion Valve
- OPT Code: 1P248TAN03600A
- Phase: Single
- Prop 65: YES
- Rated Load Amps (RLA): 18.5
- Sound Level (dBA): 66-68
- Stages Cooling: 2
- Stages Heating: 2
- Suction Line Fitting Type: Sweat or Braze
- Suction Line Size (OD): 7/8"
- Tier: Preferred
- UPC: See Optical
- Voltage: 208-230 VAC
- Weight: 260
- Width: 35
