Product Specs
- AHRI unit role: Outdoor
- AHRI model/pattern: 290VAN024**AA*
- AHRI records represented: 120
- AHRI equipment type: Central HP
- AHRI tonnage: 1.95
- AHRI refrigerant: R-454B
- Verified catalog model: 290VAN02400A
- Verified product family: 290VAN
- Verified catalog brand: Bryant
- Catalog Model: 290VAN02400A
- Manufacturer Number: 290VAN02400A
- Catalog SKU: 1604089257891242
- Catalog Brand: Bryant
- Product Family: 290VAN
- Tonnage: 2
- SEER2: 20
- Refrigerant: R-454B
- Approvals: UL Listed
- Brand: Bryant
- CFM: 2,570
- Color: Dusk Brown
- Compressor Type: Rotary
- Condenser Coil Fins Per Inch (FPI): 20
- Condenser Fan Blade Diameter: 18
- Condenser Fan CFM: 2570
- Condenser Fan Discharge: Vertical
- Condenser Fan Motor Qty: 1
- Condenser Motor HP: 1/5
- Condenser Motor RPM: 200-1,000
- Condenser Motor Speeds: Variable
- Condenser Motor Type: ECM (Electronically Commutated Motor)
- Cooling Capacity: 24,000
- Cooling Rated Capacity Btu/h: 24000
- Country Of Origin: USA
- Cycle/Hertz: 60 Hz
- EER2: 11.5
- Energy Star Rated: YES
- Full Load Amps: 0.7
- HSPF2: 9.5
- Heating Capacity: 12,500-28,000
- Height: 35.5
- Inverter: YES
- Length: 23.2
- Liquid Line Fitting Type: Sweat or Braze
- Liquid Line Size (OD): 3/8"
- Locked Rotor Amps (LRA): 11.7
- Maximum Overcurrent Protection (MOCP): 25
- Metering Device: EEV - Electronic Expansion Valve
- OPT Code: 1P290VAN02400A
- Phase: Single
- Prop 65: YES
- Rated Load Amps (RLA): 11.7
- Sound Level (dBA): 56-71
- Stages Cooling: Variable
- Stages Heating: Variable
- Suction Line Fitting Type: Sweat or Braze
- Suction Line Size (OD): 3/4"
- Tier: Evolution
- UPC: See Optical
- Voltage: 208-230 VAC
- Weight: 147
- Width: 23.2
