Product Specs
- AHRI unit role: Outdoor
- AHRI model/pattern: 37MUHAQ60AA3
- AHRI records represented: 18
- AHRI equipment type: Central HP
- AHRI tonnage: 4.5
- AHRI refrigerant: R-454B
- Verified catalog model: 37MUHAQ60AA3
- Verified product family: 37MUHA
- Verified catalog brand: Carrier, Bryant
- Catalog Model: 37MUHAQ60AA3
- Manufacturer Number: 37MUHAQ60AA3
- Catalog SKU: 1604089257813507
- Catalog Brand: Carrier, Bryant
- Product Family: 37MUHA
- Tonnage: 5
- SEER2: 17.5
- Refrigerant: R-454B
- Approvals: ETL Listed
- Brand: Carrier, Bryant
- CFM: 712-1,800
- Color: White
- Compressor Type: Rotary
- Condenser Coil Fins Per Inch (FPI): 20
- Condenser Fan Blade Diameter: 20.9
- Condenser Fan CFM: 2649
- Condenser Fan Discharge: Horizontal
- Condenser Fan Motor Qty: 1
- Condenser Motor HP: 1/8
- Condenser Motor RPM: 1,000
- Condenser Motor Speeds: 4
- Condenser Motor Type: PSC (Permanent Split Capacitor)
- Cooling Capacity: 11,400-60,000
- Cooling Rated Capacity Btu/h: 11400
- Country Of Origin: CHN
- Cycle/Hertz: 60 Hz
- EER2: 12
- Energy Star Rated: YES
- Full Load Amps: 1.2
- Heating Capacity: 8,100-64,500
- Heating Capacity @ 5 Deg: 54000
- Height: 52.48
- High Heat: YES
- Length: 16.34
- Liquid Line Fitting Type: Flare
- Liquid Line Size (OD): 3/8"
- Maximum Overcurrent Protection (MOCP): 40
- Maximum Piping Height: 98.4'
- Maximum Piping Length: 246
- Metering Device: EEV - Electronic Expansion Valve
- OPT Code: 1P37MUHAQ60AA3
- Phase: Single
- Prop 65: YES
- Rated Current Amps (RCA): 7.47
- Rated Load Amps (RLA): 7.47
- Refrigerant Charge: 11.46
- Sound Level (dBA): 65
- Stages Cooling: 1
- Stages Heating: 1
- Suction Line Fitting Type: Flare
- Suction Line Size (OD): 3/4"
- Tier: Performance
- UPC: See Optical
- Voltage: 208-230 VAC
- Weight: 240.08
- Width: 37.48
