Product Specs
- AHRI unit role: Indoor
- AHRI model/pattern: 45MUAAQ36XX3
- AHRI records represented: 2
- AHRI equipment type: Central HP
- AHRI tonnage: 3
- AHRI refrigerant: R-454B
- Verified catalog model: 45MUAAQ36XX3
- Verified product family: 45MUAA
- Verified catalog brand: Carrier, Bryant
- Catalog Model: 45MUAAQ36XX3
- Manufacturer Number: 45MUAAQ36XX3
- Catalog SKU: 1604089257813331
- Catalog Brand: Carrier, Bryant
- Product Family: 45MUAA
- Tonnage: 3
- Refrigerant: R-454B
- Air Flow Direction: Multi-Position
- Approvals: ETL Listed; UL Listed
- Blower Motor HP: 1/2
- Blower Motor RPM: 685
- Blower Motor Speeds: 3
- Blower Motor Type: ECM (Electronically Commutated Motor)
- Brand: Carrier, Bryant
- CFM: 865.24-1,188.97
- Cabinet Width: 21
- Color: Gray
- Cooling Capacity: 36,000
- Cooling Rated Capacity Btu/h: 36000
- Country Of Origin: CHN
- Cycle/Hertz: 60 Hz
- Drain Connection Size: 3/4"
- Electric Heat Range [kW]: 5-20
- Energy Star Rated: YES
- Evaporator Coil Fins Per Inch (FPI): 20
- Filter Size: 19 1/2" x 20" x 1
- Heating Capacity: 11,000-48,000
- Height: 49.02
- Includes Filter Rack: YES
- Length: 21.02
- Liquid Line Fitting Type: Flare
- Liquid Line Size (OD): 3/8"
- Maximum Overcurrent Protection (MOCP): 15
- Metering Device: EEV - Electronic Expansion Valve
- Mounting Type: Ducted Multi-Position
- OPT Code: 1P45MUAAQ36XX3
- Phase: Single
- Prop 65: YES
- Suction Line Fitting Type: Flare
- Suction Line Size (OD): 3/4"
- Tier: Standard
- UPC: See Optical
- Voltage: 115 VAC; 208-230 VAC
- Weight: 129.41
- Width: 21.02
