Product Specs
- AHRI unit role: Indoor
- AHRI model/pattern: 45MUHAQ24XX3
- AHRI records represented: 2
- AHRI equipment type: Central HP
- AHRI tonnage: 2
- AHRI refrigerant: R-454B
- Verified catalog model: 45MUHAQ24XX3
- Verified product family: 45MUHA
- Verified catalog brand: Carrier, Bryant, Payne
- Catalog Model: 45MUHAQ24XX3
- Manufacturer Number: 45MUHAQ24XX3
- Catalog SKU: 1604089262396594
- Catalog Brand: Carrier, Bryant, Payne
- Product Family: 45MUHA
- Tonnage: 2
- Refrigerant: R-454B
- Approvals: ETL Listed; UL Listed
- Blower Motor HP: 1/5
- Blower Motor RPM: 816-903
- Blower Motor Speeds: 3
- Blower Motor Type: ECM (Electronically Commutated Motor)
- Blower Motor Watts: 197
- Blower Wheel Diameter: 12 1/2
- Blower Wheel Width: 7 1/5
- Brand: Carrier, Bryant, Payne
- CFM: 629.8-824
- CFM Heating: 629.8-824
- Color: Gray
- Cooling Capacity: 18,000-24,000
- Cooling Rated Capacity Btu/h: 24000
- Country Of Origin: MEX
- Cycle/Hertz: 60 Hz
- Energy Star Rated: YES
- Evaporator Coil Fins Per Inch (FPI): 20
- Heating Capacity: 18,600-20,600
- Height: 53.875
- Length: 21.5
- Liquid Line Fitting Type: Flare
- Liquid Line Size (OD): 3/8"
- Metering Device: EEV - Electronic Expansion Valve
- OPT Code: 1P45MUHAQ24XX3
- Phase: Single
- Prop 65: YES
- Sound Level (dBA): 33-47.5
- Suction Line Fitting Type: Flare
- Suction Line Size (OD): 3/4"
- Tier: Performance
- UPC: See Optical
- Voltage: 208-230 VAC
- Weight: 123.02
- Width: 14.5
