Bryant Evaporator coil FG5ANXB24L*

Schedule Service Check Availability
Bryant Bryant AHRI Indoor - FG5 Evaporator coil Repair, maintenance, and replacement planning
Bryant FG5ANXB24L* product image

Technical Specifications

Product Specs

  • AHRI unit role: Indoor
  • AHRI model/pattern: FG5ANXB24L*
  • AHRI records represented: 19
  • AHRI equipment type: Central HP
  • AHRI tonnage: 1.525
  • AHRI refrigerant: R-454B
  • Verified catalog model: FG5ANXB24L00
  • Verified product family: FG5
  • Verified catalog brand: Carrier, Bryant, Payne
  • Catalog Model: FG5ANXB24L00
  • Manufacturer Number: FG5ANXB24L00
  • Catalog SKU: 1604089257123664
  • Catalog Brand: Carrier, Bryant, Payne
  • Product Family: FG5
  • Tonnage: 2
  • Refrigerant: R-454B
  • Air Flow Direction: Multi-Position
  • Approvals: UL Listed
  • Blower Motor HP: 1/2
  • Blower Motor Speeds: Variable
  • Blower Motor Type: ECM (Electronically Commutated Motor)
  • Brand: Carrier, Bryant, Payne
  • CFM: 525-1,050
  • Cabinet Width: 17
  • Color: Gray
  • Cooling Capacity: 24,000
  • Cooling Rated Capacity Btu/h: 24000
  • Country Of Origin: MEX
  • Cycle/Hertz: 60 Hz
  • Energy Star Rated: NO
  • Filter Size: 16" x 20
  • Height: 42.6875
  • Includes Filter Rack: YES
  • Length: 22.0625
  • Liquid Line Fitting Type: Sweat or Braze
  • Liquid Line Size (OD): 3/8"
  • Maximum Overcurrent Protection (MOCP): 15
  • Metering Device: TXV/TEV - Thermostatic Expansion Valve
  • OPT Code: 1PFG5ANXB24L00
  • Phase: Single
  • Prop 65: YES
  • Suction Line Fitting Type: Sweat or Braze
  • Suction Line Size (OD): 3/4"
  • Tier: Sentry
  • Voltage: 208-230 VAC
  • Weight: 124
  • Width: 17.625

Useful troubleshooting details

  • Confirm the installed model and serial number, matched indoor or outdoor equipment, voltage, refrigerant, controls, and AHRI certificate before service or replacement planning.
  • Use the linked AHRI certificates to verify matched-system combinations, rebate conversations, and equipment eligibility before quoting replacement work.
  • Collect photos of the nameplate, equipment access, recent fault history, and comfort symptoms before dispatch or proposal planning.

Certification match

AHRI certificates

View All
Eligible Central HP <5.4 tons

AHRI 217399917

AHRI 217399917 identifies a Mass Save qualified Central HP <5.4 tons from BRYANT HEATING AND COOLING SYSTEMS with outdoor unit 37MUHAQ18AA3+TIC2025-0016 and indoor unit FG5ANXB24L*.
Eligible Central HP <5.4 tons

AHRI 217632821

AHRI 217632821 identifies a Mass Save qualified Central HP <5.4 tons from BRYANT HEATING AND COOLING SYSTEMS with outdoor unit 37MUHAQ24AA3+TIC2025-0016 and indoor unit FG5ANXB24L*.
Eligible Central HP <5.4 tons

AHRI 217952502

AHRI 217952502 identifies a Mass Save qualified Central HP <5.4 tons from BRYANT HEATING AND COOLING SYSTEMS with outdoor unit 249VAN024**AA* and indoor unit FG5ANXB24L*.
Eligible Central HP <5.4 tons

AHRI 216640207

AHRI 216640207 identifies a Mass Save qualified Central HP <5.4 tons from BRYANT HEATING AND COOLING SYSTEMS with outdoor unit 37MUHAQ18AA3 and indoor unit FG5ANXB24L*.
Eligible Central HP <5.4 tons

AHRI 216640225

AHRI 216640225 identifies a Mass Save qualified Central HP <5.4 tons from BRYANT HEATING AND COOLING SYSTEMS with outdoor unit 37MURAQ24AA3 and indoor unit FG5ANXB24L*.
Eligible Central HP <5.4 tons

AHRI 216728038

AHRI 216728038 identifies a Mass Save qualified Central HP <5.4 tons from BRYANT HEATING AND COOLING SYSTEMS with outdoor unit 37MUHAQ24AA3 and indoor unit FG5ANXB24L*.
ENERGY STAR certified HP - Split System

AHRI 214179847

AHRI 214179847 identifies a Mass Save qualified HP - Split System from BRYANT HEATING AND COOLING SYSTEMS with outdoor unit 235SAN024**AA* and indoor unit FG5ANXB24L*.
ENERGY STAR certified HP - Split System

AHRI 214179850

AHRI 214179850 identifies a Mass Save qualified HP - Split System from BRYANT HEATING AND COOLING SYSTEMS with outdoor unit 246SAN024**AA* and indoor unit FG5ANXB24L*.
ENERGY STAR certified HP - Split System

AHRI 214179853

AHRI 214179853 identifies a Mass Save qualified HP - Split System from BRYANT HEATING AND COOLING SYSTEMS with outdoor unit GH5SAN524**AA* and indoor unit FG5ANXB24L*.
ENERGY STAR certified HP - Split System

AHRI 214179856

AHRI 214179856 identifies a Mass Save qualified HP - Split System from BRYANT HEATING AND COOLING SYSTEMS with outdoor unit PH5SAN524**AA* and indoor unit FG5ANXB24L*.
Loading more

Service planning

How GreenFlow handles FG5ANXB24L* requests

1

Identify the equipment

Confirm the model or series name, serial number if available, photos, and whether the unit is roof, exterior, basement, or mechanical-room equipment.

2

Describe the service issue

Share no heat, no cooling, weak airflow, error codes, alarms, leaks, noise, control problems, or comfort complaints.

3

Review access and history

Include access notes, tenant or business-hour constraints, filter status, recent repairs, and maintenance records when available.

4

Plan the next step

GreenFlow can route the request for diagnostics, repair planning, maintenance, replacement scope, or related system upgrades.
