Product Specs
- AHRI unit role: Outdoor
- AHRI model/pattern: GH5SAN519**AA*
- AHRI records represented: 84
- AHRI equipment type: HP - Split System
- AHRI refrigerant: R-454B
- Verified catalog model: GH5SAN51900A
- Verified product family: GH5SAN5
- Verified catalog brand: Carrier, Bryant
- Catalog Model: GH5SAN51900A
- Manufacturer Number: GH5SAN51900A
- Catalog SKU: 1604089268376873
- Catalog Brand: Carrier, Bryant
- Product Family: GH5SAN5
- Tonnage: 1.5
- SEER2: 14.3-16
- Refrigerant: R-454B
- Approvals: UL Listed
- Brand: Carrier, Bryant
- CFM: 2,300
- Color: Gray
- Compressor Type: Scroll
- Condenser Coil Fins Per Inch (FPI): 20
- Condenser Fan Blade Diameter: 23
- Condenser Fan CFM: 2300
- Condenser Fan Discharge: Vertical
- Condenser Fan Motor Qty: 1
- Condenser Motor HP: 1/12
- Condenser Motor RPM: 800
- Condenser Motor Speeds: 1
- Condenser Motor Type: PSC (Permanent Split Capacitor)
- Cooling Capacity: 18,100-19,800
- Cooling Rated Capacity Btu/h: 19000
- Country Of Origin: MEX
- Cycle/Hertz: 60 Hz
- EER2: 10-12.5
- Energy Star Rated: NO
- Full Load Amps: 0.5
- HSPF2: 7.5-7.8
- Heating Capacity: 10,500-11,000
- Height: 36.1
- Inverter: NO
- Length: 40.1
- Liquid Line Fitting Type: Sweat or Braze
- Liquid Line Size (OD): 3/8"
- Locked Rotor Amps (LRA): 45.1
- Maximum Overcurrent Protection (MOCP): 15
- Metering Device: TXV/TEV - Thermostatic Expansion Valve
- OPT Code: 1PGH5SAN51900A
- Phase: Single
- Prop 65: YES
- Rated Load Amps (RLA): 8.3
- Sound Level (dBA): 71
- Stages Cooling: 1
- Stages Heating: 1
- Suction Line Fitting Type: Sweat or Braze
- Suction Line Size (OD): 5/8"
- Tier: Standard
- UPC: See Optical
- Voltage: 208-230 VAC
- Weight: 148
- Width: 40.1
