Product Specs
- AHRI unit role: Outdoor
- AHRI model/pattern: 27SPA636A**30*
- AHRI records represented: 30
- AHRI equipment type: HP - Split System
- AHRI refrigerant: R-454B
- Verified catalog model: 27SPA636A003
- Verified product family: 27SPA6
- Verified catalog brand: Carrier
- Catalog Model: 27SPA636A003
- Manufacturer Number: 27SPA636A003
- Catalog SKU: 1604089243199192
- Catalog Brand: Carrier
- Product Family: 27SPA6
- Tonnage: 3
- SEER2: 16
- Refrigerant: R-454B
- Approvals: UL Listed
- Brand: Carrier
- CFM: 3,500
- Color: Gray
- Compressor Type: Scroll
- Condenser Coil Fins Per Inch (FPI): 20
- Condenser Fan Blade Diameter: 24
- Condenser Fan CFM: 3500
- Condenser Fan Discharge: Vertical
- Condenser Fan Motor Qty: 1
- Condenser Motor HP: 1/4
- Condenser Motor RPM: 825
- Condenser Motor Speeds: 1
- Condenser Motor Type: PSC (Permanent Split Capacitor)
- Cooling Capacity: 36,000
- Country Of Origin: USA
- Cycle/Hertz: 60 Hz
- EER2: 10
- Energy Star Rated: YES
- Full Load Amps: 1.2
- HSPF2: 7.5
- Heating Capacity: 33,200-37,600
- Height: 32.0625
- Inverter: NO
- Length: 31.1875
- Liquid Line Fitting Type: Sweat or Braze
- Liquid Line Size (OD): 3/8"
- Locked Rotor Amps (LRA): 86
- Maximum Overcurrent Protection (MOCP): 30
- Metering Device: TXV/TEV - Thermostatic Expansion Valve
- OPT Code: 1P27SPA636A003
- Phase: Single
- Prop 65: YES
- Rated Load Amps (RLA): 14.4
- Sound Level (dBA): 74
- Stages Cooling: 1
- Stages Heating: 1
- Suction Line Fitting Type: Sweat or Braze
- Suction Line Size (OD): 3/4"
- Tier: Performance
- UPC: See Optical
- Voltage: 208-230 VAC
- Weight: 189
- Width: 31.1875
