Product Specs
- AHRI unit role: Outdoor
- AHRI model/pattern: 27TPA848A**30*
- AHRI records represented: 430
- AHRI equipment type: HP - Split System
- AHRI refrigerant: R-454B
- Verified catalog model: 27TPA848A003
- Verified product family: 27TPA8
- Verified catalog brand: Carrier
- Catalog Model: 27TPA848A003
- Manufacturer Number: 27TPA848A003
- Catalog SKU: 1604089257712132
- Catalog Brand: Carrier
- Product Family: 27TPA8
- Tonnage: 4
- SEER2: 18
- Refrigerant: R-454B
- Approvals: UL Listed
- Brand: Carrier
- CFM: 1,120
- Color: Gray
- Compressor Type: Scroll
- Condenser Coil Fins Per Inch (FPI): 20
- Condenser Fan Blade Diameter: 26
- Condenser Fan CFM: 4781
- Condenser Fan Discharge: Vertical
- Condenser Fan Motor Qty: 1
- Condenser Motor HP: 1/3
- Condenser Motor RPM: 815
- Condenser Motor Speeds: 1
- Condenser Motor Type: ECM (Electronically Commutated Motor)
- Cooling Capacity: 44,500-50,500
- Country Of Origin: USA
- Cycle/Hertz: 60 Hz
- EER2: 14
- Energy Star Rated: YES
- Full Load Amps: 2.6
- HSPF2: 8.5
- Heating Capacity: 48,000
- Height: 45.6875
- Inverter: NO
- Length: 35
- Liquid Line Fitting Type: Sweat or Braze
- Liquid Line Size (OD): 3/8"
- Locked Rotor Amps (LRA): 138
- Maximum Overcurrent Protection (MOCP): 50
- Metering Device: TXV/TEV - Thermostatic Expansion Valve
- OPT Code: 1P27TPA848A003
- Phase: Single
- Prop 65: YES
- Rated Load Amps (RLA): 23
- Sound Level (dBA): 70
- Stages Cooling: 2
- Stages Heating: 2
- Suction Line Fitting Type: Sweat or Braze
- Suction Line Size (OD): 7/8"
- Tier: Performance
- UPC: See Optical
- Voltage: 208-230 VAC
- Weight: 309
- Width: 35
