Product Specs
- Model: 48FCEM28A2A5-0A0A0
- Manufacturer Number: 48FCEM28A2A5-0A0A0
- Vendor Number: 48FCEM28A2A5-0A0A0
- Catalog Brand: Carrier®
- Product Family: 48FC
- AHRI Usage: Packaged
- Air Flow Direction: Vertical
- Approvals: AHRI Certified; cULus
- BTU Input: 248,000-310,000
- BTU Output: 200,000-251,000
- Blower Motor HP: 3 BHP
- Blower Motor RPM: 250-2,000
- Blower Motor Speeds: Variable
- Blower Motor Type: ECM (Electronically Commutated Motor)
- Blower Wheel Diameter: 22"
- Brand: Carrier®
- CFM: 4,950-12,500
- Color: Rhino
- Compressor Type: Scroll
- Condenser Coil Fins Per Inch (FPI): 18
- Condenser Fan Blade Diameter: 22
- Condenser Fan Motor Qty: 4
- Condenser Motor HP: 1/4
- Condenser Motor RPM: 1,100
- Condenser Motor Speeds: 1
- Condenser Motor Type: PSC (Permanent Split Capacitor)
- Cooling Capacity: 282,000
- Cooling Rated Capacity Btu/h: 300000
- Country Of Origin: MEX
- Cubic Measurement: 447.3333
- Cycle/Hertz: 60 Hz
- Drain Connection Size: 3/4"
- Drive Type: Direct
- EER: 9.8
- Energy Star Rated: NO
- Evaporator Coil Fins Per Inch (FPI): 15
- Evaporator Coil Metering Device: TXV/TEV - Thermostatic Expansion Valve
- Fuel Type: Natural Gas or LP
- Gas Connection Size: 3/4"
- Gas Connection Type: NPT
- Height: 57.375
- IEER: 14
- Length: 86.375
- Locked Rotor Amps (LRA): 245
- Maximum Overcurrent Protection (MOCP): 175
- OPT Code: 1P48FCEM28A2A5-0A0A0
- Outdoor Air Filter Size (OA) In Inches (W X H X D): (4) 16 x 25 x 1
- Phase: Three
- Prop 65: YES
- Rated Load Amps (RLA): 48.1
- Refrigerant: R-410A
- Return Air Filter Size (RA) In Inches (W X H X D): (9) 20 x 25 x 2
- Sound Level (dBA): 85.9
- Stages Cooling: Variable
- Stages Heating: 2
- Thermal Efficiency: 81%
- Tier: WeatherMaker®
- Tonnage: 25
- UPC: See Optical
- Voltage: 208-230 VAC
- Weight: 2174
- Width: 141.5
