Product Specs
- Model: 48HCDD14K1M5-6U5G0
- Manufacturer Number: 48HCDD14K1M5-6U5G0
- Vendor Number: 48HCDD14K1M5-6U5G0
- Catalog Brand: Carrier®
- Product Family: 48HC
- AHRI Usage: Packaged
- Air Flow Direction: Convertible
- BTU Input: 120,000-150,000
- BTU Output: 96,000-120,000
- Blower Motor HP: 2 9/10
- Blower Motor RPM: 591-838
- Blower Wheel Diameter: 18"
- Blower Wheel Width: 18"
- Brand: Carrier®
- CFM Heating: 1,880-7,500
- Color: Gray
- Compressor Type: Scroll
- Condenser Coil Fins Per Inch (FPI): 17
- Condenser Coil Metering Device: TXV/TEV - Thermostatic Expansion Valve
- Condenser Fan Blade Diameter: 22
- Condenser Fan Motor Qty: 3
- Condenser Motor HP: 3/4
- Condenser Motor RPM: 1,100
- Condenser Motor Type: PSC (Permanent Split Capacitor)
- Cooling Capacity: 146,000
- Country Of Origin: Varies
- Cycle/Hertz: 60 Hz
- Drain Connection Size: 3/4"
- Drive Type: Belt
- EER: 12.2
- Energy Star Rated: NO
- Evaporator Coil Fins Per Inch (FPI): 15
- Evaporator Coil Metering Device: TXV/TEV - Thermostatic Expansion Valve
- Fuel Type: Natural Gas or LP
- Height: 57.375
- Ignition Type: Direct Spark (DSI)
- Length: 63.375
- Locked Rotor Amps (LRA): 136
- Maximum Overcurrent Protection (MOCP): 80
- Outdoor Air Filter Size (OA) In Inches (W X H X D): Vertical (2) 24 x 27 x 1, Horizontal 30 x 39 x 1
- Phase: Three
- Rated Load Amps (RLA): 19.6
- Refrigerant: R-410A
- Return Air Filter Size (RA) In Inches (W X H X D): (6) 18 x 24 x 2
- Sound Level (dBA): 83
- Stages Cooling: 2
- Stages Heating: 2
- Thermal Efficiency: 80%
- Tier: WeatherMaster®
- Tonnage: 12.5
- Voltage: 208-230 VAC
- Weight: 1430
- Width: 115.875
