Product Specs
- Model: 48LCD017A2M6-0R5C0
- Manufacturer Number: 48LCD017A2M6-0R5C0
- Vendor Number: 48LCD017A2M6-0R5C0
- Catalog Brand: Carrier®
- Product Family: 48LC
- AHRI Usage: Packaged
- Air Flow Direction: Vertical
- Approvals: ETL Listed; UL Listed
- BTU Input: 176,000-220,000
- BTU Output: 142,000-178,000
- Blower Motor HP: 7 2/5 BHP
- Blower Motor RPM: 707-888
- Blower Motor Speeds: 3
- Blower Motor Type: Belt Drive
- Brand: Carrier®
- CFM: 1,500-7,500
- CFM Heating: 3,000-8,250
- Color: Gray
- Compressor Type: Scroll
- Condenser Coil Fins Per Inch (FPI): 18
- Condenser Fan Blade Diameter: 22
- Condenser Fan Motor Qty: 4
- Condenser Motor HP: 1/3
- Condenser Motor RPM: 1,000
- Condenser Motor Type: ECM (Electronically Commutated Motor)
- Cooling Capacity: 174,000
- Country Of Origin: Varies
- Cycle/Hertz: 60 Hz
- Drain Connection Size: 3/4"
- Drive Type: Belt
- EER: 12.5
- Energy Star Rated: NO
- Evaporator Coil Fins Per Inch (FPI): 15
- Evaporator Coil Metering Device: TXV/TEV - Thermostatic Expansion Valve
- Fuel Type: Natural Gas or LP
- Gas Connection Size: 3/4"
- Gas Connection Type: NPT
- Height: 53.375
- IEER: 18.4
- Length: 141.5
- Maximum Overcurrent Protection (MOCP): 60
- OPT Code: 1P48LCD017A2M6-0R5C0
- Outdoor Air Filter Size (OA) In Inches (W X H X D): (4) 16 x 25 x 1
- Phase: Three
- Prop 65: YES
- Refrigerant: R-410A
- Return Air Filter Size (RA) In Inches (W X H X D): (9) 16 x 25 x 2
- Sound Level (dBA): 86
- Stages Cooling: 3
- Stages Heating: 2
- Thermal Efficiency: 81%
- Tier: WeatherExpert®
- Tonnage: 15
- UPC: See Optical
- Voltage: 460 VAC
- Weight: 2095
- Width: 86.375
