Product Specs
- Model: 50VL-K60---5
- Manufacturer Number: 50VL-K60---5
- Vendor Number: 50VL-K60---5
- Catalog Brand: Carrier®
- Product Family: 50VL-K
- AHRI Usage: Packaged
- Air Flow Direction: Convertible
- Blower Motor HP: 1
- Blower Motor RPM: 1,040
- Blower Motor Type: ECM (Electronically Commutated Motor)
- Blower Wheel Diameter: 11"
- Blower Wheel Width: 10"
- Brand: Carrier®
- CFM: 1,750
- Color: Gray
- Compressor Type: Scroll
- Condenser Coil Fins Per Inch (FPI): 21
- Condenser Fan Blade Diameter: 26
- Condenser Fan CFM: 3500
- Condenser Fan Motor Qty: 1
- Condenser Motor HP: 1/5
- Condenser Motor RPM: 810
- Condenser Motor Speeds: 1
- Condenser Motor Type: PSC (Permanent Split Capacitor)
- Cooling Capacity: 56,000
- Country Of Origin: MEX
- Cycle/Hertz: 60 Hz
- Drain Connection Size: 3/4"
- Drive Type: Direct
- Energy Star Rated: NO
- Evaporator Coil Fins Per Inch (FPI): 17
- Evaporator Coil Metering Device: TXV/TEV - Thermostatic Expansion Valve
- Height: 55
- Length: 48
- Locked Rotor Amps (LRA): 93
- Maximum Overcurrent Protection (MOCP): 70
- OPT Code: 1P50VL-K60---5
- Phase: Three
- Prop 65: YES
- Rated Load Amps (RLA): 13.5
- Refrigerant: R-410A
- Return Air Filter Size (RA) In Inches (W X H X D): (1) 24 x 18 x 1; (1) 24 x 16 x 1
- Sound Level (dBA): 76.6
- Stages Cooling: 1
- Tier: Comfort™
- Tonnage: 5
- UPC: See Optical
- Voltage: 208-230 VAC
- Weight: 514
- Width: 44
