Carrier Catalog Product CRSMKDET002C00 - Return Air Smoke Detector

Install QuoteBook ServiceEquipment Quote
Carrier Residential Carrier Catalog Product Carrier Catalog Product Repair, maintenance, and replacement planning
Carrier CRSMKDET002C00 - Return Air Smoke Detector product image

Technical Specifications

Product Specs

  • Model: CRSMKDET002C00
  • Manufacturer Number: CRSMKDET002C00
  • Vendor Number: CRSMKDET002C00
  • Catalog Brand: Carrier®, Bryant®, Payne®
  • Audible Alert: NO
  • Battery Backup: NO
  • Brand: Carrier®, Bryant®, Payne®
  • Country Of Origin: USA
  • Cubic Measurement: 0.1389
  • Cycle/Hertz: 50/60 Hz
  • Detection Method: Photoelectric
  • Dimensional Weight: 2
  • Display: NO
  • Height: 1
  • Hush Button: NO
  • Interconnection Capability: NO
  • Length: 60
  • Locking Pin: NO
  • Mounting Type: 48/50A Units - install in the predrilled holes located in the indoor section above the auxiliary control box; 48/50P Units - install on the upright in the power exhaust section
  • OPT Code: 1PCRSMKDET002C00
  • Operating Temperature Range: 32°F to 131°F (0°C to 55°C)
  • Power Source: Hard wired
  • Prop 65: YES
  • Sensor Type: Photoelectric
  • Test Button: NO
  • Tier: Standard
  • Type: Return Smoke Detector
  • UPC: See Optical
  • Visual Alert: NO
  • Voltage: 24 VAC
  • Weight: 25
  • Width: 4

Useful troubleshooting details

  • Confirm the exact model number, serial number, installed equipment type, and site voltage before service or replacement planning.
  • Match replacement equipment and accessories against current Carrier compatibility requirements, refrigerant type, capacity, airflow, and local code requirements.

Service planning

How GreenFlow handles CRSMKDET002C00 - Return Air Smoke Detector requests

1

Identify the equipment

Confirm the model or series name, serial number if available, photos, and whether the unit is roof, exterior, basement, or mechanical-room equipment.

2

Describe the service issue

Share no heat, no cooling, weak airflow, error codes, alarms, leaks, noise, control problems, or comfort complaints.

3

Review access and history

Include access notes, tenant or business-hour constraints, filter status, recent repairs, and maintenance records when available.

4

Plan the next step

GreenFlow can route the request for diagnostics, repair planning, maintenance, replacement scope, or related system upgrades.
