Product Specs
- Model: TP-PHP01-A
- Manufacturer Number: TP-PHP01-A
- Vendor Number: TP-PHP01-A
- Catalog Brand: Carrier®, RCD Parts
- 750mV Compatible: NO
- Approvals: CSA Listed
- Auto Changeover: YES
- Backlit: YES
- Batteries Included: NO
- Battery Backup: NO
- Brand: Carrier®, RCD Parts
- Built In Wi-Fi: NO
- Change/Check Reminders: YES
- Color: White
- Country Of Origin: USA
- Cubic Measurement: 0.0148
- Daylight Savings Time Ready: YES
- Digital-Non Programmable: NO
- Digital-Programmable: YES
- Dimensional Weight: 1
- Display: YES
- Display Options: Backlit, Digital, LCD
- Displays Outdoor Temperature: YES
- Dual Transformer Compatible: YES
- Electrical Connection Type: Terminals
- Electrical Rating: 24 VAC, 3 VA, RC/RH compatible
- Energy Star Rated: NO
- Fan Switching: YES
- Heat Pump Compatible: YES
- Height: 1
- Hinged: NO
- Humidification: NO
- Indoor Remote Sensor: NO
- Language: English
- Length: 5.1
- Low Battery Indicator: NO
- Manual: YES
- Mounting Type: Vertical or horizontal J-box provisions
- OPT Code: TP-PHP01-A
- Operating Temperature Range: 32°F to 104°F (0°C to 40°C)
- Power Method: Hardwired
- Programmable Fan: YES
- Prop 65: YES
- Removable Interface: NO
- Sensing Element: YES
- Stages Cooling: 2
- Stages Heating: 3
- System Switching: YES
- Temperature Range: 50°F to 90°F (10°C to 32.22°C)
- Temperature Settings Per Day: 4
- Terminal Designations: OAT, RRS, SRTN, HUM, D1, D2, V+, Vg, Rc, Rh, W/W1, G, Y/Y2, C, O/W2/B, Y1
- Tier: Performance™
- Touchscreen: NO
- UOM: EA
- UPC: See Optical
- Vacation Mode: YES
- Voltage: 24 VAC
- Weight: 0.5
- Width: 5
- Works With Google Assistant: NO
- Works With Rheem EcoNet: NO
