Kenmore Heat pump condensing unit N5H8T24*K*AAA*

Schedule Service Check Availability
Kenmore Kenmore AHRI Outdoor - Performance 18 Two-Stage Heat Pump Heat pump condensing unit Repair, maintenance, and replacement planning
Kenmore N5H8T24*K*AAA* product image

Technical Specifications

Product Specs

  • AHRI unit role: Outdoor
  • AHRI model/pattern: N5H8T24*K*AAA*
  • AHRI records represented: 512
  • AHRI equipment type: HP - Split System
  • AHRI refrigerant: R-454B
  • Verified catalog model: N5H8T24*K*AAA*
  • Verified product family: Performance 18 Two-Stage Heat Pump
  • Verified catalog brand: Kenmore
  • Verified ENERGY STAR dataset: ENERGY STAR Certified Heat Pumps
  • ENERGY STAR partner: Carrier Corporation
  • ENERGY STAR outdoor brand: Kenmore
  • ENERGY STAR series: 2-STAGE 18 SEER HP
  • ENERGY STAR outdoor model: N5H8T24*K*AAA*
  • ENERGY STAR indoor model: FTMA5X24L0B*
  • Matched-system SEER2: 17.50
  • Matched-system EER2: 13.00
  • Matched-system HSPF2: 8.10
  • Matched-system cooling capacity: 23,200 BTU/h
  • Matched-system heating capacity at 47F: 24,800 BTU/h
  • Matched-system heating capacity at 17F: 14,600 BTU/h
  • Compressor staging: Two-stage
  • Refrigerant: R-454B (GWP:470 | Lower GWP)
  • ENERGY STAR certified date: 2025-01-30
  • ENERGY STAR source dataset: https://data.energystar.gov/d/83eb-xbyy
  • Carrier-family public product page: https://www.airquestcomfort.com/en/us/products/heat-pumps/performance-two-stage-heat-pump-n5h8t
  • Verified Carrier-family model family: N5H8T
  • AHRI model/pattern: N5H8T24*K*AAA*
  • Nominal capacity: 2 ton
  • Nominal cooling capacity: 24,000 BTU nominal cooling capacity
  • Compressor: two-stage scroll
  • Sound level: as low as 69 dBA

Useful troubleshooting details

  • Confirm the installed model and serial number, matched indoor or outdoor equipment, voltage, refrigerant, controls, and AHRI certificate before service or replacement planning.
  • Use the linked AHRI certificates to verify matched-system combinations, rebate conversations, and equipment eligibility before quoting replacement work.
  • Collect photos of the nameplate, equipment access, recent fault history, and comfort symptoms before dispatch or proposal planning.

Certification match

AHRI certificates

View All
ENERGY STAR certified HP - Split System

AHRI 215560673

AHRI 215560673 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T24*K*AAA* and indoor unit FTMA5X24L0B*.
ENERGY STAR certified HP - Split System

AHRI 215613834

AHRI 215613834 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T24*K*AAA* and indoor unit EVM5X31M17A*.
ENERGY STAR certified HP - Split System

AHRI 215614034

AHRI 215614034 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T24*K*AAA* and indoor unit EVM5X31M17A*.
ENERGY STAR certified HP - Split System

AHRI 215614115

AHRI 215614115 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T24*K*AAA* and indoor unit EVM5X31M17A*.
ENERGY STAR certified HP - Split System

AHRI 215614278

AHRI 215614278 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T24*K*AAA* and indoor unit EVM5X31M17A*.
ENERGY STAR certified HP - Split System

AHRI 215614355

AHRI 215614355 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T24*K*AAA* and indoor unit EVM5X32M17A*.
ENERGY STAR certified HP - Split System

AHRI 215614382

AHRI 215614382 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T24*K*AAA* and indoor unit EVM5X32M17A*.
ENERGY STAR certified HP - Split System

AHRI 215614424

AHRI 215614424 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T24*K*AAA* and indoor unit EVM5X32M17A*.
ENERGY STAR certified HP - Split System

AHRI 215614728

AHRI 215614728 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T24*K*AAA* and indoor unit EVM5X32M17A*.
ENERGY STAR certified HP - Split System

AHRI 215614876

AHRI 215614876 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T24*K*AAA* and indoor unit EVM5X32M17A*.
Loading more

Service planning

How GreenFlow handles N5H8T24*K*AAA* requests

1

Identify the equipment

Confirm the model or series name, serial number if available, photos, and whether the unit is roof, exterior, basement, or mechanical-room equipment.

2

Describe the service issue

Share no heat, no cooling, weak airflow, error codes, alarms, leaks, noise, control problems, or comfort complaints.

3

Review access and history

Include access notes, tenant or business-hour constraints, filter status, recent repairs, and maintenance records when available.

4

Plan the next step

GreenFlow can route the request for diagnostics, repair planning, maintenance, replacement scope, or related system upgrades.
