Canonical product data

Specifications

Product Type: HP - Split System
Compressor Staging: Two-stage
Connected Capable: No
Cooling Capacity (Mode: cooling): 43500 Btu/h
Eer2 (Mode: cooling): 12 Btu/(W.h)
Heating Capacity (Mode: heating, Outdoor Dry Bulb: 5 degF): 32200 Btu/h
Heating Capacity (Mode: heating, Outdoor Dry Bulb: 47 degF): 44000 Btu/h
Heating Capacity (Mode: heating, Outdoor Dry Bulb: 17 degF): 29200 Btu/h
Heating Cop (Mode: heating, Outdoor Dry Bulb: 5 degF): 2.2
Hspf2 (Mode: heating): 9 Btu/(W.h)
Refrigerant With Gwp Claim: R-454B (GWP:470 | Lower GWP)
Seer2 (Mode: cooling): 17.1 Btu/(W.h)

AHRI 216759840

AHRI 216759840 identifies a Mass Save qualified Central HP <5.4 tons from TRANE with outdoor unit 5TWR7048A1 and indoor unit 5TXCD010AS3.

Mass Save eligible Central HP <5.4 tons

AHRI 217138189

AHRI 217138189 identifies a Mass Save qualified Central HP <5.4 tons from TRANE with outdoor unit 5TWR7048A1 and indoor unit H,TE48*48+TXV+TD.

Mass Save eligible Central HP <5.4 tons

AHRI 217138190

AHRI 217138190 identifies a Mass Save qualified Central HP <5.4 tons from TRANE with outdoor unit 5TWR7048A1 and indoor unit TA*61C*+TXV+TD.

Mass Save eligible Central HP <5.4 tons

AHRI 217138191

AHRI 217138191 identifies a Mass Save qualified Central HP <5.4 tons from TRANE with outdoor unit 5TWR7048A1 and indoor unit TA*61D*+TXV+TD.

Mass Save eligible Central HP <5.4 tons

AHRI 217138192

AHRI 217138192 identifies a Mass Save qualified Central HP <5.4 tons from TRANE with outdoor unit 5TWR7048A1 and indoor unit H,TE49*60+TXV+TD.

Mass Save eligible Central HP <5.4 tons

AHRI 217138193

AHRI 217138193 identifies a Mass Save qualified Central HP <5.4 tons from TRANE with outdoor unit 5TWR7048A1 and indoor unit TA*48C*+TXV+TD.

Mass Save eligible Central HP <5.4 tons

AHRI 217138194

AHRI 217138194 identifies a Mass Save qualified Central HP <5.4 tons from TRANE with outdoor unit 5TWR7048A1 and indoor unit TA*48D*+TXV+TD.

Mass Save eligible Central HP <5.4 tons

AHRI 218011046

AHRI 218011046 identifies a Mass Save qualified Central HP <5.4 tons from TRANE with outdoor unit 5TWR7048A1 and indoor unit V,T60H245P18*+TXV+AEFE5*.
