Air-source heat pump
WEATHERMAKER PH5SAN548**AA*
- Category
- Air-source heat pump
- Series
- 15 SEER2 HP
- Model record
- Model pattern
- Certifications
- 5 linked
Canonical product data
Specifications
- Product Type
- HP - Split System
- Compressor Staging
- Single stage
- Connected Capable
- No
- Cooling Capacity (Mode: cooling)
- 47500 Btu/h
- Eer2 (Mode: cooling)
- 12 Btu/(W.h)
- Heating Capacity (Mode: heating, Outdoor Dry Bulb: 5 degF)
- 23600 Btu/h
- Heating Capacity (Mode: heating, Outdoor Dry Bulb: 47 degF)
- 47500 Btu/h
- Heating Capacity (Mode: heating, Outdoor Dry Bulb: 17 degF)
- 30000 Btu/h
- Heating Cop (Mode: heating, Outdoor Dry Bulb: 5 degF)
- 2.26
- Hspf2 (Mode: heating)
- 7.8 Btu/(W.h)
- Refrigerant With Gwp Claim
- R-454B (GWP:470 | Lower GWP)
- Seer2 (Mode: cooling)
- 15.5 Btu/(W.h)
AHRI 214179634
- Brand
- BRYANT HEATING AND COOLING SYSTEMS
- Outdoor model
- PH5SAN548**AA*
- Indoor model
- FJ5AN*D60L*
AHRI 214179635
- Brand
- BRYANT HEATING AND COOLING SYSTEMS
- Outdoor model
- PH5SAN548**AA*
- Indoor model
- PF5MN*D60L*
AHRI 214179636
- Brand
- PAYNE HEATING AND COOLING
- Outdoor model
- PH5SAN548**AA*
- Indoor model
- FJ5AN*D60L*
AHRI 214179637
- Brand
- PAYNE HEATING AND COOLING
- Outdoor model
- PH5SAN548**AA*
- Indoor model
- PF5MN*D60L*
AHRI 214179638
- Brand
- WEATHERMAKER
- Outdoor model
- PH5SAN548**AA*
- Indoor model
- PF5MN*D60L*
AHRI 214179639
- Brand
- BROCK
- Outdoor model
- PH5SAN548**AA*
- Indoor model
- PF5MN*D60L*
AHRI 214180113
- Brand
- BRYANT HEATING AND COOLING SYSTEMS
- Outdoor model
- PH5SAN548**AA*
- Indoor model
- FT5ANBD60L*
AHRI 214180114
- Brand
- BRYANT HEATING AND COOLING SYSTEMS
- Outdoor model
- PH5SAN548**AA*
- Indoor model
- FG5ANBD60L*
