Gas furnace

Back to Kenmore products

Kenmore Gas furnace *80VSL1102122B*

Schedule Service Check Availability
Kenmore Kenmore AHRI Furnace - Performance 80 Variable-Speed Low NOx Gas Furnace Gas furnace Repair, maintenance, and replacement planning
Kenmore *80VSL1102122B* product image

Technical Specifications

Product Specs

  • AHRI unit role: Furnace
  • AHRI model/pattern: *80VSL1102122B*
  • AHRI records represented: 75
  • AHRI equipment type: HP - Split System
  • AHRI refrigerant: R-410A
  • Verified catalog model: *80VSL1102122B*
  • Verified product family: Performance 80 Variable-Speed Low NOx Gas Furnace
  • Verified catalog brand: Kenmore
  • Verified ENERGY STAR dataset: ENERGY STAR Certified Heat Pumps
  • ENERGY STAR partner: Carrier Corporation
  • ENERGY STAR outdoor brand: Kenmore
  • ENERGY STAR series: 15 SEER2 R SERIES R410A HP
  • ENERGY STAR outdoor model: R4H5S36*K*AAA*
  • ENERGY STAR indoor model: EA*4X43L21A*
  • ENERGY STAR furnace model: *80VSL1102122B*
  • Matched-system SEER2: 15.20
  • Matched-system EER2: 12.00
  • Matched-system HSPF2: 7.80
  • Matched-system cooling capacity: 34,600 BTU/h
  • Matched-system heating capacity at 47F: 33,600 BTU/h
  • Matched-system heating capacity at 17F: 20,200 BTU/h
  • Compressor staging: Single stage
  • Refrigerant: R-410A (GWP:2088)
  • ENERGY STAR certified date: 2023-08-21
  • ENERGY STAR source dataset: https://data.energystar.gov/d/83eb-xbyy
  • Carrier-family public product page: https://www.airquestcomfort.com/en/us/products/gas-furnaces/performance-80-gas-furnace-n80vsl
  • Verified Carrier-family model family: N80VSL
  • AHRI furnace model/pattern: *80VSL1102122B*
  • Nominal input: 110,000 BTU/h input
  • AFUE family: 80%
  • Heating stages: single-stage
  • Blower: variable-speed
  • NOx classification: low NOx
  • Cabinet width code: 21
  • Application: matched gas furnace for split-system air conditioner or heat pump combinations

Useful troubleshooting details

  • Confirm the installed model and serial number, matched indoor or outdoor equipment, voltage, refrigerant, controls, and AHRI certificate before service or replacement planning.
  • Use the linked AHRI certificates to verify matched-system combinations, rebate conversations, and equipment eligibility before quoting replacement work.
  • Collect photos of the nameplate, equipment access, recent fault history, and comfort symptoms before dispatch or proposal planning.

Certification match

AHRI certificates

View All
ENERGY STAR certified HP - Split System

AHRI 213209365

AHRI 213209365 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit R4H5S36*K*AAA* and indoor unit EA*4X43L21A*.
ENERGY STAR certified HP - Split System

AHRI 214161083

AHRI 214161083 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit (C,H,T)5H6S24*K*AAA* and indoor unit EA*5X37M21A*.
ENERGY STAR certified HP - Split System

AHRI 214211219

AHRI 214211219 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H5S24*K*AAA* and indoor unit EA*5X37M21A*.
ENERGY STAR certified HP - Split System

AHRI 214211220

AHRI 214211220 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit R5H5S24*K*AAA* and indoor unit EA*5X37M21A*.
ENERGY STAR certified HP - Split System

AHRI 215619511

AHRI 215619511 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T36*K*AAA* and indoor unit EVM5X48M21A*.
ENERGY STAR certified HP - Split System

AHRI 215620938

AHRI 215620938 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T36*K*AAA* and indoor unit EVD5X37M21A*.
ENERGY STAR certified HP - Split System

AHRI 215622486

AHRI 215622486 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T36*K*AAA* and indoor unit EVD5X48M21A*.
ENERGY STAR certified HP - Split System

AHRI 215622930

AHRI 215622930 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T48*K*AAA* and indoor unit EVM5X48M21A*.
ENERGY STAR certified HP - Split System

AHRI 215623287

AHRI 215623287 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T48*K*AAA* and indoor unit EVM5X49M21A*.
ENERGY STAR certified HP - Split System

AHRI 215623685

AHRI 215623685 identifies a Mass Save qualified HP - Split System from Kenmore with outdoor unit N5H8T48*K*AAA* and indoor unit EVM5X60M21A*.
Loading more

Service planning

How GreenFlow handles *80VSL1102122B* requests

1

Identify the equipment

Confirm the model or series name, serial number if available, photos, and whether the unit is roof, exterior, basement, or mechanical-room equipment.

2

Describe the service issue

Share no heat, no cooling, weak airflow, error codes, alarms, leaks, noise, control problems, or comfort complaints.

3

Review access and history

Include access notes, tenant or business-hour constraints, filter status, recent repairs, and maintenance records when available.

4

Plan the next step

GreenFlow can route the request for diagnostics, repair planning, maintenance, replacement scope, or related system upgrades.
